B-MV Metering Valves
MV Metering Valves is a distributor elements for economical light equipment. CISO's MV Standard material is Brass. Carbon steel can be customized.
Action pressure: ≧ 1.5MPa
Back pressure: ≦ 0.5MPa
Max. pressure: 8MPa
Standard outlet: 4mm, sleeve or ferrule for choice
Technical Information of B-MV Metering Valves
Technical characteristics | |
Outlets | 1 to 8 |
Flow rate | 0.06ml, 0.1ml, 0.2ml, 0.3ml, 0.4ml, 0.5ml |
Lubricant | NLGI 0, 00,000 |
Operating temperature | –30 to +170 °C |
Operating pressure | Max. 8 Mpa |
Material | brass, steel |
Connection main line | M10*1 |
| Connection outlet | 4mm in O.D. tube |
| Lubrication system | single line lubrication system |
Characteristics of B-MV Metering Valves
Pressurized ration distributor valve
Standard material: Brass
Reliable and efficient
Measured Accurately, Stable performance
Dual-seal、Leak-tightness
Cisolube offers custom grease distributor with wide selections, Contact now.
